More information about ORACAL 751 361 G Apple Red Glossy
ORACAL 751 in 361 G Apple Red is a glossy, cast high-performance PVC plotter film in a dark red shade. The film is available in a width of 126 cm; you can select the length to suit your needs as a linear metre variant from 1 to 50 linear metres.
According to ORAFOL, the ORACAL 751C High Performance Cast series was developed for plotter applications and is suitable for lettering, markings and decorations. It can be applied to painted, including uneven or curved surfaces, as well as in recesses and over rivets.
- Colour code: 361 G Apple Red, glossy surface
- Width: 126 cm; lengths: 1, 2, 3, 4, 5, 10, 15, 20, 25, 30, 35, 40, 45 or 50 linear metres
- For high-quality vehicle and transport advertising as well as general plotter lettering
| Resistance to cleaning agents |
No change | applied to aluminium |
|---|---|
| Durability |
with vertical outdoor exposure, Central European normal climate
|
| Shelf life |
2 year(s) | in original packaging, at 20 °C and 50% relative humidity |
| Solvent/chemical resistance |
Oils,
|
| Maximum shrinkage |
Maximum longitudinal shrinkage 0.15 mm
|
| Elongation at break |
Minimum longitudinal elongation at break 120 %
|
| Tensile strength |
Minimum longitudinal tensile strength: 19 N/mm²
|
| Seawater resistance |
No change | after 100h/35°C | applied to aluminium, DIN EN ISO 9227 |
| Temperature resistance |
Minimum temperature: -40 °C
|
| Water resistance |
Recommended | at 23° C, applied to aluminium | no change after 100h |
| Adhesive power |
18 N/25 mm | after 24h, stainless steel | FINAT TM 1, average value |
| Adhesive power level |
Permanent |
| Recommended printing procedure |
Digital thermal transfer printing |
| Application temperature |
Minimum temperature 10 °C |
| Thickness |
0.06 mm | average value, without backing paper and adhesive |
| Format |
Roll |
| Standard width |
1260 mm
|
| Standard length |
50 m |
ORACAL 751C – cast premium film for vehicles and long-term applications
ORAFOL Adhesive Films – Professional Film Solutions for Advertising and Design
